Experiment Manual Solar Power Case
Documents for the Teacher

Russian

Item No.: 19130

Add to wish list

Beware! This experiment manual is only delivered to customers who have also purchased the Solar Power Case (75636 or 76704) from Christiani.
The instructions for the Solar Power Case are divided into a:

Information section
task part and a
Solutions section

and forms an essential part of the didactic concept.

Introduction:

Safety Instructions
Learning Objectives
Device description
Operating instructions
Notes on didactics and methodology
Information about photovoltaics
Test questions
References

Experiments:

Circuit with solar module and consumer
Current-voltage characteristic curve and power diagram at different illuminance levels
Open-circuit voltage, short-circuit current and internal resistance at different illuminance levels
Direct supply of various consumers with solar power
Solar power system with accumulator
Discharge protection diode in a solar power system
Charge controller for solar power systems
Saving energy by using energy-saving lamps and PIR motion detectors
