Experiment Manual Solar Power Case
Documents for the Teacher

Spanish
Item No.: 77650

Beware! This experiment manual is only delivered to customers who have also purchased the Solar Power Case (75636 or 76704) from Christiani.
The instructions for the Solar Power Case are divided into a:

  • Information section
  • task part and a
  • Solutions section

and forms an essential part of the didactic concept.

Introduction:

  • Safety Instructions
  • Learning Objectives
  • Device description
  • Operating instructions
  • Notes on didactics and methodology
  • Information about photovoltaics
  • Test questions
  • References

Experiments:

  • Circuit with solar module and consumer
  • Current-voltage characteristic curve and power diagram at different illuminance levels
  • Open-circuit voltage, short-circuit current and internal resistance at different illuminance levels
  • Direct supply of various consumers with solar power
  • Solar power system with accumulator
  • Discharge protection diode in a solar power system
  • Charge controller for solar power systems
  • Saving energy by using energy-saving lamps and PIR motion detectors
