Experiment Manual Solar Power Case
Documents for the Students

Spanish

Item No.: 83304

Add to wish list

Important! This experiment manual is only supplied to customers who also have the Christiani solar power case (75636 or 76704).

black-and-white, loose-leaf

The comprehensive experiment manual "Students documents" contains basic information on photovoltaics, the general information and the worksheets, but not the worksheet solutions.

Introduction:

Safety Instructions
Learning Objectives
Device description
Operating instructions
Notes on didactics and methodology
Information about photovoltaics
Test questions
References

Experiments:

Circuit with solar module and consumer
Current-voltage characteristic curve and power diagram at different illuminance levels
Open-circuit voltage, short-circuit current and internal resistance at different illuminance levels
Direct supply of various consumers with solar power
Solar power system with accumulator
Discharge protection diode in a solar power system
Charge controller for solar power systems
Saving energy by using energy-saving lamps and PIR motion detectors
