Machine-based Material Processing - Part: Turning
Documents for the Trainer

Chinese
Item No.: 45076

The training course "Mechanical Materials Processing - Turning Part" deals with the machining production processes of turning in accordance with the training framework plans for metal professions (Lfd. No. 12 c "Turning"). The various turning skills such as centering, drilling, thread production, taper turning, knurling and deburring are dealt with in detail. A second focus is on the lathes and their functions, as well as on professional operation and the testing and adjustment of machine functions. In addition, the tools, the alignment and clamping of tools and workpieces are described.
Various project tasks are dealt with in 12 practical exercises, each with work information, parts lists and work planning forms as well as control and evaluation sheets. The exercises are structured according to the lead text method and follow the model of the complete action. Thus they are particularly conducive to action and social competence. The exercises can be worked on both individually and in groups.
The complete training course in a collective folder, consisting of the trainer's set with trainer's guide, slides on CD, text volume, learning success controls and suggested solutions as well as the documents for the trainee.
Processing time: approx. 5 weeks

  • Assign skill Turning
  • Explain the structure and function of a center lathe
  • Making the lathe ready for operation
  • Distinguish clamping devices for workpieces and clamp workpieces in a three-jaw chuck
  • Distinguishing between clamping devices for tools and clamping turning tools
  • Naming and selecting turning tools
  • Setting the frequency of rotation, feed and infeed
  • Measuring clamped workpieces
  • Name and apply safety and accident prevention regulations and environmental protection measures
  • Explain chip formation and chip types
  • Centering workpieces
  • Explanation of material designation
  • Differentiate surface quality according to DIN 1302
  • Determine rotation frequency
  • Distinguishing between turning tool types and cutting materials
  • Identifying angles at the cutting edge of a tool and showing correlations
  • Explain undercut according to DIN 76-A
  • Make internal threads and fitting holes
  • Workpiece is fixed by a rotating centering point
  • Properties of thermoplastics
  • Machining of polyethylene (PE)
  • Clamping of workpieces (PE)
  • Distinguish between inner and outer radii
  • Name profile turning tool shapes
  • Describe work steps for the production of inner and outer radii
  • Distinguish, select and describe parting and grooving
  • Deepening of skills (transverse facing, longitudinal turning, centering, drilling, parting off, deburring)
  • Calculation for taper production
  • Taper manufacture and taper testing
  • Distinguish and select knurl types
  • Describe knurling technique
  • Measuring with the outside micrometer
  • Distinguish ISO tolerances/fits
  • Produce threaded bolts
  • Independent planning and execution of operational work on the lathe
  • Describe working technique for internal turning
