2. edition 2014, approx. 170 pages in a folder
The training workbook "Machine - based material processing - Part: Milling" deals
with the metalremoving process of milling. It provides a detailed description of
the various milling methods, e.g. surface milling using either a face milling cutter,
a peripheral milling cutter or an end milling cutter, and longitudinal profile milling.
It also presents the various types of milling machines and their functions, provides
instruction in professional machine operation and the review and setting of the
production parameters, and describes the necessary tools as well as the fitting
and adjustment of the tools and workpieces.
The project "Drill stand" is dealt with in 13 practical exercises, each accompanied
by work information, parts lists and work planning sheets as well as inspection
and evaluation sheets. The exercises are structured according to the "Leittext"
method and are based on the end-to-end process model. This approach fosters both
working and social competence.
The exercises are equally suitable for individual
and group work.
This comprises the complete work section in one file and comprises the trainer guidelines, the trainee work sheets and the textbook. Digital transparencies in printable quality are available for download.
Anticipated time required: approx. 4 weeks
- Classify milling processes
- Explain the design and function of a milling machine
- Establish the operational readiness of a milling machine
- Distinguish between milling tools
- Select and fit appropriate toolholders
- Clamp and align workpieces
- Identify and setting of production parameters
- Measure clamped workpieces
- Explain and use health and safety regulations and environmental protection measures
- Identify angles and surfaces on the cutting tool and highlight interdependencies (cutting geometry)
- Distinguish between milling processes according to DIN
- Set and operate the feed
- Distinguish between different types of milling machines
- Distinguish between milling processes depending on the intended surface type
- Assemble tool blocks and indexable inserts that are appropriate for the task
- Recognise tool wear and eliminate extreme causes of wear
- Check and evaluate results
- Plan procedures
- Present planning results
- Use and reinforce work techniques
- Carry out and distinguish between milling work using the dividing head
Take a look at the sample now.
