The objectives of this exercise book correspond to the specifications of the BIBB and offer practice-oriented training in the different levels of on/off hydraulics. The successful completion of the practical exercises provides hands-on knowledge of the use of manually-operated on/off valves as well as the function and effect of the main components and basic circuits of on/off hydraulics is acquired.
The following exercises are included:
| No. | Exercise | Industrial applications |
|---|---|---|
| 01 | Hydraulic load holding 1 | Press with a pressing load |
| 02 | Hydraulic load holding 2 | Hydraulic lift |
| 03 | Workpiece fixation | Press-in device for joining workpieces |
| 04 | Material feed of a press | Workpiece feed of a press by means of a swivel arm and a hydraulic motor |
| 05 | Motion of a lock gate | Opening and closing a lock gate by means of hydraulic cylinders |
| 06 | Hydraulic cylinders with pulling load | Storm bulkhead of a barrage |
| 07 | Lifting device | Pallet stacker |
With the help of logically structured, practice-related exercises, the trainee shall learn the following:
