Mobile hydraulics – Hydrostatic steering systems (according to BIBB)
Exercise Book for the Trainee

English

Item No.: 55709

Add to wish list

The exercise books are tailored to the device sets. These device sets build on the contents and knowledge from the "On/off hydraulics – Manual operation (BIBB, A-H)" and "Mobile hydraulics – Load-sensing control" learning topics.

The described exercises and tasks provide basic information and methods. The setup is structured in a uniform manner and provides the step-by-step description for completion of the individual exercises.

The following exercises are included:

No.	Exercise
01	Getting to know the steering system
02	Flow/steering speed characteristic curve
03	Frame size of a steering unit
04	Operation force at the steering wheel (incl. emergency steering function)
05	Priority valve
06	Ackermann steering
07	Articulated steering
08	Wheel loader with articulated steering (application circuit)

With the help of logically structured, practice-related exercises, the trainee shall learn the following:

understand physical laws of hydraulics such as pressure difference, opening cross-section and flow,
get to know and use specific graphical symbols,
understand the function of the load-sensing control,
get to know components such as 4/3 directional control valve, load holding valve, primary and secondary valve, pressure compensator, hydraulic pilot control,
understand the connection between control and velocity,
get to know the function of the load-sensing control in parallel operation,
work out the function and application of the hydraulic pilot control,
determine characteristic values and derive characteristic curves from them, if required.
