To purchase the software, you must also purchase a 12-month Software Maintenance Agreement, Article no. 55779, after which you will receive an optional offer to extend the Software Maintenance.
SINUMERIK Operate Training Software
The new user interface for efficient machine operation
The new SINUMERIK user interface is now even clearer and more intuitive. SINUMERIK Operate combines the well-known HMI-Advanced, ShopMill and ShopTurn under one consistent, innovative operating and programming interface.
SINUMERIK Operate is clearly arranged, intuitively operable and equipped with a large number of new, powerful functions. This enables the combination of work step and high-level language programming under one user interface and thus very fast, rational and intuitive NC programming and work preparation.
- ShopTurn & ShopMill
Work step programming - ProgramGUIDE
graphical programming with animated elements - DIN/ISO & SINUMERIK High level language
maximum programming freedom
CNC programs created with SinuTrain for SINUMERIK Operate can be used on real machines. However, this requires an adaptation of SinuTrain to the SINUMERIK configuration of the machine. The adaptation can either be carried out by the user using the configuration tool that can be purchased separately for OEMs or by means of a service that can be ordered. Several different configurations can be stored in SinuTrain for SINUMERIK Operate so that a larger machine park can be operated. To ensure maximum compatibility with different SINUMERIK software versions on the machine, SinuTrain for SINUMERIK Operate can be installed several times in the corresponding software versions on a PC.
Intelligent functions support the operator in his daily work in the simplest possible way - e.g. screenshots with the key combination CTRL+P.
SINUMERIK Operate is also a new standard in user-friendliness when it comes to graphical support. Animated elements are a helpful function in this respect, as they anticipate every processing step and display it graphically animated.
Simple steps for successful working (Features)
When setting up a workpiece, the measuring process is presented clearly and concisely by animated elements. Complex workpieces can be manufactured in one clamping by simple and fast handling. Different kinematics are easy to set up.
If desired, the drawing of the machining or the simulation can be activated
and displayed.
SINUMERIK Operate combines the whole orchestra of functions
for operating and programming in one user interface for efficient machine
operation.
News
- Automation License Manager V6.0 HF1
- Windows 10 sharing (as well as Windows 8.1 and Windows 7)
- Integration of several SINUMERIK CNC-SW packages in one user interface
- Extension of the display resolutions incl. 16:9
- SinuTrain Workbench with new functions
- Operation via menu strip and icons
- Tile display of all user machines can be arranged with Drag & Drop
- Info tile to display important properties of the selected machine
- Assignment of user image files
- Creation and management of user templates including labelling with your own logo (not for SinuTrain Basic)
- Multi-window mode: dockable sub-windows "Mesh control panel" and "Control panel" in the machine simulation
- Integration of SINUMERIK Integrate Run MyScreens
- Takeover of the OEM-specific tool management
- The delivery is carried out via a USB stick and a link to the software.
- To obtain the corresponding data carrier, the corresponding DVD can be ordered (SinuTrain Basic).
Programming, simulation, printing
- DIN/ISO programming with programGUIDE
- ShopMill/ShopTurn work step programming
- Multi-channel programming with programSYNC (only SinuTrain Complete)
- Full graphic CNC-simulation
- TCP/IP Ethernet networking with machines
- Print function for DIN/ISO and ShopMill/ShopTurn work step programs
- Integrated CAD reader for the import of DXF files
Languages
Operational in: German, English, French, Italian, Simplified Chinese, Spanish
Hardware
- Processor 2 GHz (single core)
- RAM 4 GB
- Storage space approx. 3.2 GB for complete installation
- Graphics card: minimum resolution 640 * 480 pixels
- mouse, keyboard
Operating system
- MS Windows 7 Home Basic, Home Premium, Professional, Ultimate, Enterprise (32- and 64-bit)
- MS Windows 8.1, MS Windows 8.1 Pro, Enterprise (32- and 64-bit)
- MS Windows 10 (64-bit | not supported: Mobile, Mobile Enterprise)
Software
- Adobe Reader® software
User profile
- To install SinuTrain you need administrator rights
The delivery takes place via a link to the software.
The functional scope is activated with the corresponding license key depending on the order. SinuTrain uses the Automation License Manager (ALM) to protect against unauthorized copying.
The presence of an "old" SinuTrain licence key in the ALM serves as proof of purchase of a SinuTrain licence and is a requirement for all update versions. The USB stick and the license number encryption also contain information on whether the license is a single license or a classroom license (with number of PC seats).
Limitations of the Basic version
Use and scope of functions of the various template engines depend on whether you have a license. Without a license, only the Basic version is available to you.
For the template machines "DEMO-Lathe" (1-channel 3-axis machine with main spindle and driven tool spindle) and "DEMO-Milling Machine" (1-channel 3-axis machine) you do not need a license. You can, for example, transfer workpieces and part programs to the machine for program simulation and adaptation and then exit the machine for further use on CNC controls.
