Mechanical Engineering - Marking out with Marking Gauge; Files and Filing

Mechanical Engineering - Marking out with Marking Gauge; Files and Filing
Documents for the Trainer

Arabic
Item No.: 99599
Add to wish list

1st edition 2016, 28 pages, format A4, wire-stitched

Content:

  • Scribing with the parallel scriber
  • The U-steel
  • The workshop file
  • Changing the file handle
  • Filing technique
  • Deburring and checking the flatness


Duration :

approx. 12 hours

  • Marking the legs of a U-steel on a marking plate
  • Clamp a U-steel for filing the legs centrally in the parallel vice
  • Explain the motion sequence when filing the legs of the U-steel
