Mechanical Engineering - Filing Flats to Right Angles and Parallel in Bar Stock

Mechanical Engineering - Filing Flats to Right Angles and Parallel in Bar Stock
Documents for the Trainer

Arabic
Item No.: 99736
Add to wish list

1st edition 2016, 9 pages, A4, stitched

Content:

  • Specification of the groove direction
  • Processing sequence of the surfaces when filing a square
  • Marking according to existing surfaces on the round steel bar


Duration:

approx. 16 hours

  • Clamping round steel bars aligned with prism inserts
  • File circular surfaces flat and at right angles on a round steel
  • Filing a square on a round steel
  • Mark out and file further surfaces
