Experiment instructions for alternating current technology

Determination and visualisation of parameters in alternating current technology:

• Basics
• Characteristics of sinusoidal voltage
• Active power with sinusoidal voltage
• Characteristics of rectangular alternating voltage

Three-phase alternating current (three-phase current):

• Basics
• Voltage curve for three-phase systems
• Load in star connection
• Load in delta connection
• Measurements on faulty star connection
• Measurements on faulty delta connection

Capacitor in an AC circuit:

• Basic principles
• Charging and discharging process of a capacitor
• Phase shift between current and voltage on the capacitor
• Capacitive reactance of a capacitor
• Series connection of capacitors
• Parallel connection of capacitors
• Reactive power of a capacitor

Coil in an alternating current circuit:

• Basic principles
• Switching on and off process on a coil
• Phase shift between current and voltage on a coil
• Inductive reactance of a coil
• Series connection of coils
• Parallel connection of coils
• Reactive power of a coil

Interconnection of resistor, capacitor and coil:

• Basic principles
• Series connection of resistor and capacitor
• Parallel connection of resistor and capacitor
• Series connection of resistor and coil
• Parallel connection of resistor and coil
• Series connection of capacitor and coil
• Parallel connection of capacitor and coil
• Series connection of resistor, capacitor and coil
• Parallel connection of resistor, capacitor and coil
• Active, reactive and apparent power

Transformer, transformer:

• Basic principles
• Coupling ratio
• Transformation ratio
• Resistance transformation

Experiment instructions "Alternating current technology" (incl. CD-ROM)
