As a trainer in manual or industrial electrical professions, you are investing in long-term didactic materials to accompany your training with this switch cabinet material set.
The modular concept allows you to continue using the control cabinet for future learning situations. Either with our extension modules or by own extensions.
You can connect functional models (sensors, actuators, safety circuit, motors) via the interfaces in the side panel. The switch cabinet easily fits on a work table and can be worked on comfortably in standing or sitting position. With the included exercise sheet made of aluminium and the corresponding work order, this project is also suitable for beginner exercises in sheet metal working.
The superordinate work order for the basic module material set is: processing, equipping, assembly and wiring of the control cabinet with a rectified voltage 24V DC.
Learning fields
1. Analyse electrotechnical systems and test their functions
2. Plan and
execute electrical installations
3. Analyse and adapt control systems
Work tasks (extract)
- Mechanical processing
- Construction of the basic carrier, production of a practice plate, making the cut-outs for the side plates, processing and assembly of the side and front plates.
- Mounting and wiring Preparation of the mounting plate, mounting of the mounting plate, mounting of the side and front panels, mounting of the mounting plate, mounting of the main switch, the push buttons, basic wiring of the mounting plate, wiring of the safety relay, production of the printed circuit board for the low voltage supply.
- Testing and commissioning
Visual inspection, acceptance certificate according to DIN VDE 0100 part
610, commissioning.
Contains basics about:
- Calipers
- Marking and graining
- Drilling
- Lowering
- Thread cutting
- Sheet metal punching
- Dimensions
- Files
- Deburring
- Wire colours
- Protective earth connection
- Soldering
- Practice measurement DIN VDE 0100
- Mechanical processing
- Tip
- Grains
- Files
- Saws
- Drilling
- Punching
- Deburring
- Assembly
- Install
- Mounting
- Confectioning
- Screwing
- Connect
- Wiring
- Plug in
- Connect
- Soldering technology
- Interconnection
- Soldering
- Contact
- Commissioning
- Control
- Check
