3rd edition 2012, approx. 340 pages in the file, four-colour
As a trainer in technical or industrial electronics professions, by acquiring this material kit for a switching cabinet, you are investing in didactic materials which can accompany training over the long term.
The modular concept allows you to use the switching cabinet again for future learning situations, either by using our enhancement modules or with your own enhancements. You can connect functional models via the interfaces in the side wall (sensors, actuators, safety circuit, motors). The switch cabinet fits easily on a work bench and can be conveniently worked on whether you are standing or sitting.
This project contains an aluminium practice sheet and an accompanying task, making it suitable for practice in sheet metal working, even for beginners. The primary task for the basic module material kit is: processing, equipping, assembly and wiring the switch cabinet, using a rectified voltage of 24 V DC.
1. Analysing electrotechnical systems and testing functions
2. Planning
and carrying out electrical installations
3. Analysing and adapting control
systems
- Mechanical processing
- Tip
- Grains
- Files
- Saws
- Drilling
- Punching
- Deburring
- Assembly
- Install
- Mounting
- Confectioning
- Screwing
- Connect
- Wiring
- Plug in
- Connect
- Soldering technology
- Interconnection
- Soldering
- Contact
- Commissioning
- Control
- Check
- Exhibitions
-
Mechanical processing
Marking, centre punching, filing, sawing, drilling, punching, deburring -
Assembly
Installing, mounting, preparing, screwing, connecting -
Wiring
Connecting to the mains, connecting -
Soldering technology
Wiring, soldering, contacting -
Commissioning
Checking, testing, measuring
Mechanical processing
Assembly of the base support, making a practice
sheet, creating the cut-outs for the side panels, processing and assembling the
side and front panel.
Assembling and wiring
Preparing the mounting plate, equipping the mounting
plate, equipping the side and front panel, installing the mounting plate, fitting
the main switch and the buttons, basic wiring of the mounting plate, wiring the
safety relay, making the PCB for the low voltage supply.
Testing and commissioning
Visual inspection, acceptance report in accordance
with DIN VDE 0100 Part 610, commissioning.
Contains basic information on:
- Calliper gauge
- Marking and punching
- Drilling
- Countersinking
- Thread cutting
- Punching holes in sheet metal
- Dimensioning
- Filing
- Deburring
- Conductor colours
- Protective earth connection
- Soldering
- Actual measurements DIN VDE 0100
- Activity-based, same content as for trainees
- With presentation of the training concept
- With answers to guide questions
- With work schedules filled out
- With master copies for forms
