1st edition 2015, 131 pages, DIN A4, paperback, "English language"
An experiment manual especially designed for practical application, which was primarily designed for use with the learning boards available from Christiani, but is also suitable for experiments with conventional set-ups (perforated plate or switch cabinet).
The experiment manual for electrical drive technology Part: Connection programmed control is used in the school laboratory or in the company training workshop. Starting with the basic properties of the components (e.g. contactors, timer relays, circuit breakers), the manual covers simple to complex tasks with extensive circuits.
The application of the knowledge is practised on many practical exercises,
which are supported by guiding text questions.
Finally, a complex project
task is worked on. Numerous explanations and cross-references in the margin
column encourage the use of additional tables and technical books. As in our
books of tables and technical books, this continuous margin column contains
further important information that contributes to safe and successful
experimentation.
The trainer section/teacher section:
This part contains
all relevant instructions and solutions for the exercises. This separation makes
a lot of sense in this case, since voltages above 50 V are used. Constant
supervision and control during these first steps in working with single and
three-phase mains voltage circuits is essential.
