Microcontroller 1 - Basic course with Arduino UNO

Microcontroller 1 - Basic course with Arduino UNO
Test instructions for the trainee

Item No.: 41464
Add to wish list

Note: The document cannot be used without suitable hardware. You can find the matching hardware under ‘Matching this’.

1st edition 2018, 114 pages, DIN A4, four-colour, paperback

Suitable for the supplementary set microcontroller technology for mobileLab.

The experiment instructions contain numerous programme examples and tasks for programming yourself, using simple experiments to teach the transition from discrete digital circuits to programmed logic.

For example, the basic logic operations are first realised as programmed functions. Building on these basic elements, more complex programmes with time functions and sequence controls are then developed.

The microcontroller technology supplementary set uses a microcontroller board that is based on the widely used Arduino Uno development platform and is fully compatible with it.

Tasks included in the experiment instructions:

  • Flashing circuits
  • Running light
  • Construction site traffic light
  • Dimming LEDs with PWM
  • Logical links
  • Vehicle interior lighting
  • Car indicator and hazard warning light circuit
  • RS flip-flop
  • Schmitt trigger, twilight switch
  • Text input with 2-line LCD display
  • Bar graph with 2-line LCD display
  • Simple mathematical functions
  • Analogue input with double 7-segment display
  • Counter with double 7-segment display
  • Push-button debouncing
  • Programmaufbau: Konfiguration, Ablauf, Schleifen
  • Kompilieren und Laden des Programms
  • Verwenden von Variablen
  • Auslesen von Digital- und Analogeingängen
  • LED dimmen mit PWM
  • Logische Verknüpfungen programmieren
  • LCD Display ansteuern
  • Mathematische Funktionen
  • Schalterentprellung
  • Spannung messen und anzeigen
