Experiment instructions for direct current technology

Experiment instructions for direct current technology

Item No.: 54587
Add to wish list

Note: The document cannot be used without suitable hardware.

The DC technology experiment guide covers the following topics:

  • Electrical circuit
  • Ohm's law
  • Voltage and current fault circuit
  • Electrical resistors
  • Equivalent voltage source
  • Series connection of voltage sources
  • Parallel connection of voltage sources
  • Electrical power and work
  • Efficiency of electrical power
  • Voltage, current and power adjustment

Incl. solutions

  • Electrical circuit
  • Ohm's law
  • Voltage and current error circuit
  • Electrical resistors
    • Basics
    • Linear resistor
    • NTC resistor (thermistor)
    • PTC resistor (PTC thermistor)
    • Voltage-dependent resistor (varistor)
    • Photoresistor (LDR)
    • Series connection of resistors
    • Parallel connection of resistors
    • Mixture of series and parallel connection
    • Unloaded voltage divider
    • Loaded voltage divider
  • Substitute voltage source
  • Series connection of voltage sources
  • Parallel connection of voltage sources
  • Electrical power and work
  • Efficiency of electrical power
  • Voltage, current and power adjustment

"DC technology" experiment instructions (incl. CD-ROM)

Variants
